12A-13
FUEL MIXTURE
Air inlet flap: Removal - Refitting
K9K, and 832 or 834
12A
III - FINAL OPERATION
a Connect the brake servo pipe union to the vacuum
pump.
a Fit the manual gearbox breather to its support.
a Refit the gearbox breather mounting nut.
a Clip the damper valve wiring onto the injector rail
protector cover.
a Connect:
-the camshaft position sensor connector,
-the damper valve connector,
-the intercooler outlet air pipe on the damper valve.
a Torque tighten the intercooler air outlet pipe clip
on the damper valve (5.5 N.m).
a Clip the turbocharger pressure sensor wiring onto
the intercooler air outlet pipe.
a Connect the turbocharger pressure sensor connec-
tor.
a Refit the engine cover.
