12A-22
FUEL MIXTURE
Throttle valve: Cleaning
F4R or K4M
12A
a Remove the cleaning product and the dirt residue
using lint-free CLEANING CLOTHS.
a Use a compressed air nozzle to blast the throttle
valve edges and the air vent.
III - FINAL OPERATION
a Refit the throttle valve (see 12A, Fuel mixture,
Throttle valve: Removal - Refitting, page 12A-17)
.
124737
124738
Note:
If the throttle valve is dropped or receives any
other impact, it will need to be replaced.
