12B-31
TURBOCHARGING
Turbocharger oil pipe: Removal - Refitting
F4R
12B
REMOVING THE TURBOCHARGER OIL
SUPPLY PIPE
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Disconnect the battery (see Battery : Removal -
Refitting) (80A, Battery).
a Remove:
- the engine cover,
- the engine undertray bolts,
- the engine undertray,
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) (85A, Wiping -
Washing),
- the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
- the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment),
- the upstream oxygen sensor (see 17B, Petrol in-
jection, Oxygen sensors: Removal - Refitting,
page 17B-1) ,
- the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
- the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection).
a Drain the manual gearbox (see Manual gearbox
oil: Draining - Refilling) (21A, Manual gearbox).
a Remove:
- the front right-hand wheel driveshaft (see Front ri-
ght-hand wheel driveshaft: Removal - Refitting)
(29A, Driveshafts),
- the right-hand differential output seal (see Diffe-
rential output seal: Removal - Refitting) (21A,
Manual gearbox),
- the lower engine tie-bar (see 19D, Engine moun-
ting, Lower engine tie-bar: Removal - Refitting,
page 19D-33) ,
Essential special tooling
Ms. 583 Hose clamp pliers.
Mot. 1448 Long nose pliers for hose
clips.
Tightening torquesm
turbocharger oil supply
pipe hollow bolt on the
cylinder block
45 Nm
turbocharger oil supply
pipe union on the turbo-
charger
25 N.m
oil supply pipe bolt on
the cylinder block
25 N.m
turbocharger cooling
pipe hollow bolts (initial
torque)
12 N.m
hollow bolts of the turbo-
charger cooling pipe on
the turbocharger
27 N.m
bolt for the turbochar-
ger oil pipe heat shield
on the coolant pipe hou-
sing outlet
10 N.m
turbocharger oil return
pipe bolts on the turbo-
charger
8 Nm
turbocharger oil return
pipe bolt on the cylinder
block
25 Nm
IMPORTANT
Wear protective gloves during the operation.
WARNING
Prepare for the flow of fluid, and protect the sur-
rounding components.
Note:
This procedure deals with removing and refitting the
turbocharger oil supply pipe and the turbocharger
oil return pipe.
