12B-48
TURBOCHARGING
Intercooler air inlet pipe: Removal - Refitting
F4R
12B
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: turbocharger air
cooler air inlet pipe seal (10,09,04,04).
II - REFITTING OPERATION FOR PART
CONCERNED
a Fit the intercooler air inlet pipe equipped with a new
seal.
a Clip the intercooler air inlet pipe onto the intercooler.
a Refit the bolts on the intercooler air inlet pipe.
a Connect the intercooler air inlet pipe on the turbo-
charger.
a Torque tighten the intercooler air inlet pipe clip (6
N.m).
III - FINAL OPERATION
a Refit:
-the front section of the front left-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
-the front left-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the engine undertray,
-the petrol injection computer cover,
-the battery cover,
-the engine cover.
