13B-20
DIESEL INJECTION
Camshaft position sensor: Removal - Refitting
K9K, and 832 or 834
13B
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: camshaft sensor
seal (11,11,04,02).
a Lubricate the camshaft position sensor seal with
new engine oil.
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit:
-the camshaft position sensor fitted with a new seal,
-the camshaft position sensor bolt.
a Connect the camshaft position sensor connector.
III - FINAL OPERATION
a Fit the intercooler air outlet pipe.
a Connect the intercooler air outlet pipe on the damper
valve.
a Torque tighten the intercooler air outlet pipe clip
on the damper valve (5.5 N.m).
a Refit the engine cover.
