13B-125
DIESEL INJECTION
Fuel temperature sensor: Removal - Refitting
K9K, and 830
13B
a Make sure that no impurities enter the high pressure
pump when the fuel temperature sensor is removed.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Refit the fuel temperature sensor.
a Torque tighten the fuel temperature sensor (15
N.m).
a Connect the fuel temperature sensor connector.
II - FINAL OPERATION
a Refit the injector rail protector cover.
a Clip on the injector rail protector cover.
a Refit the turbocharger air outlet pipe (see 12B, Tur-
bocharging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) .
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
a Start the engine.
a Check that there are no fuel leaks.
a Refit the engine cover.
WARNING
Do not blast with compressed air once the fuel
circuit is open, otherwise impurities may enter
the system. Only use cleaning cloths.
