14A-9
ANTIPOLLUTION
Intercooler: Removal - Refitting
K9K
14A
-the exhaust gas cooler,
-the exhaust gas cooler seal.
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: exhaust gas cooler
seal (11,07,01,17).
a parts always to be replaced: Exhaust gas recir-
culation rigid pipe (11,07,01,08).
a parts always to be replaced: Exhaust gas recir-
culation pipe seal (11,07,01,15).
a Use ABRASIVE PADS to clean the joint faces:
-of the exhaust gas cooler if it is being reused,
-of the exhaust gas recirculation mounting on the
gearbox side.
a Use ABRASIVE PADS to clean the joint faces of the
exhaust gas recirculation mounting on the timing
end.
a Use SURFACE CLEANER (see Vehicle: Parts
and ingredients for the repairwork) (04B, Consu-
mables - Products) and CLEAN CLOTHS to de-
grease the joint faces:
- of the exhaust gas cooler if it is being reused,
-of the exhaust gas recirculation mounting on the
gearbox side.
a Use SURFACE CLEANER (see Vehicle: Parts
and ingredients for the repairwork) (04B, Ingre-
dient - Products) and CLEAN CLOTHS to degrease
the joint faces of the exhaust gas recirculation
mounting on the timing end.
K9K, and 832
Note:
Ta ke care not to damage the joint faces of the
exhaust gas cooler on its mounting to prevent
any coolant leaks.
K9K, and 830
WARNING
To ensure proper sealing, the gasket surfaces
must be clean, dry and not greasy (avoid any fin-
ger marks).
K9K, and 830
