14A-11
ANTIPOLLUTION
Intercooler: Removal - Refitting
K9K
14A
-the bolts of the exhaust gas recirculation as-
sembly mounting (12 N.m).
III - FINAL OPERATION
a Refit the exhaust gas recirculation assembly (see
14A, Antipollution, Exhaust gas recirculation as-
sembly: Removal - Refitting, page 14A-18) .
a Refit the exhaust gas recirculation assembly equip-
ped with the exhaust gas recirculation rigid pipe on
the cylinder head.
a Fit without tightening:
-the bolts of the exhaust gas recirculation assembly
on the cylinder head,
- the bolts of the exhaust gas recirculation rigid pipe
bracket on the cylinder head,
- the exhaust gas recirculation rigid pipe bolts on the
exhaust manifold.
a Tighten to torque:
- the bolts of the exhaust gas recirculation as-
sembly on the cylinder head (25 N.m),
- the bolts of the exhaust gas recirculation rigid
pipe bracket on the cylinder head (25 N.m),
- the bolts of the exhaust gas recirculation rigid
pipe on the exhaust manifold (36 N.m).
a Connect the cooling hoses of the exhaust gas cooler
cover.
a Fit the clip on each cooling hose of the exhaust gas
cooler cover using the tool (Mot. 1448).
a Remove the tool (Ms. 583) on each cooling hose of
the exhaust gas cooler cover.
a Clip the hose of the turbocharging pressure regula-
tion solenoid valve onto the exhaust gas cooler co-
ver.
a Refit the air outlet pipe onto the air filter unit.
a Connect the air filter unit air outlet pipe to the turbo-
charger.
a Torque tighten the air filter unit air outlet pipe clip
on the turbocharger (5.5 N.m).
a Connect the air filter unit air outlet pipe to the air filter
unit.
a Torque tighten the clip of the air filter unit air out-
let pipe on the air filter unit (5.5 N.m).
a Clip the air flowmeter wiring onto the air filter unit air
outlet pipe.
K9K, and 830
K9K, and 832
