14A-12
ANTIPOLLUTION
Intercooler: Removal - Refitting
K9K
14A
a Refit the rigid exhaust gas recirculation pipe (see
14A, Antipollution, Exhaust gas recirculation ri-
gid pipe: Removal - Refitting, page 14A-30) .
a Refit:
-the air inlet metal tube fitted with new seals,
-the lifting eye on the timing end.
a Connect the exhaust gas recirculation solenoid val-
ve connector.
a Refit:
-the injector rail protector cover mounting,
-the injector rail protector cover.
a Clip the injector rail protector cover into place.
a Refit the damper valve (see 12A, Fuel mixture, Air
inlet flap: Removal - Refitting, page 12A-11) .
a Refit:
-the turbocharger air outlet pipe (see 12B, Turbo-
charging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) ,
-the oil vapour rebreathing pipe .
a Connect the oil vapour rebreathing pipe:
-on the rocker cover,
-on the air filter box air outlet pipe.
a Refit:
-the catalytic converter (see 19B, Exhaust, Cataly-
tic converter: Removal - Refitting, page 19B-17)
,
-the engine undertray,
-the engine cover.
a Refit:
- the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting) .
- the brake fluid reservoir of the scoop under the scu-
ttle panel grille,
- the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) ,
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) .
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
a Fill and bleed the cooling system (see 19A, Coo-
ling, Cooling circuit: Draining - Refilling, page
19A-17) .
K9K, and 830
K9K, and 832
K9K, and 832
J95
