14A-20
ANTIPOLLUTION
Exhaust gas recirculation assembly: Removal - Refitting
K9K
14A
a Remove the nut (3) from the breather mounting on
the gearbox.
a Move the breather mounting away from the gearbox.
a Remove:
- the bolts (4) of the oil vapour rebreathing valve
bracket,
- the oil vapour rebreathing valve bracket.
a Disconnect the brake servo pipe union from the va-
cuum pump.
a Remove:
- the nuts (5) of the oil vapour rebreathing valve,
- the oil vapour rebreathing valve.
K9K, and 830
135879
135845
112325
