16A-3
STARTING - CHARGING
Alternator: Removal - Refitting
K4M
16A
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the nut (5) on the alternator positive termi-
nal.
a Disconnect the alternator connector (6) .
a Move aside the alternator wiring.
a Remove:
-the alternator strut nut (7) from the cylinder block,
-the alternator strut bolt (8) from the alternator,
-the alternator strut.
a Remove:
- the alternator strut bolt (9) from the cylinder block,
- the alternator strut bolt (10) from the alternator,
- the alternator strut.
135920
K4M, and 848
135727
K4M, and 858 or 866
136573
