16A-9
STARTING - CHARGING
Alternator: Removal - Refitting
K9K
16A
-the bolts of the engine cooling fan assembly wiring
channel on the front end panel.
a Clip the expansion bottle top hose onto the front end
panel.
a Refit:
-the bonnet catch (see Bonnet latch: Removal -
Refitting) (52A, Non-side opening element mecha-
nisms),
-the front impact cross member (see Front impact
cross member: Removal - Refitting) (41A, Front
lower structure),
-the audible warning (see Horn: Removal - Refit-
ting) (82B, Horn),
-the side air deflectors of the cooling radiator,
-the top air deflector of the cooling radiator,
-the front bumper mountings (see Front bumper
support: Removal - Refitting) (42A, Front upper
structure).
-the headlights (see Front headlight: Removal -
Refitting) (80B, Headlights),
-the turbocharger air outlet pipe (see 12B, Turbo-
charging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) ,
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
-the engine undertray,
-the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
-the engine cover.
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
