19A-38
COOLING
Cooling radiator: Removal - Refitting
K9K
19A
a Fit the air conditioning condenser.
a Clip the air conditioning condenser onto the cooling
radiator.
a Refit:
-the audible warning (see Horn: Removal - Refit-
ting) (82B, Horn),
-the intercooler (see 12B, Turbocharging, Inter-
cooler: Removal - Refitting, page 12B-37) ,
-the intercooler air outlet pipe (see 12B, Turbo-
charging, Intercooler air outlet pipe: Removal -
Refitting, page 12B-56) ,
-the intercooler air inlet pipe (see 12B, Turbochar-
ging, Intercooler air inlet pipe: Removal - Refit-
ting, page 12B-41) ,
-the turbocharger air outlet pipe (see 12B, Turbo-
charging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) ,
-the front bumper supports (see Front bumper
support: Removal - Refitting) (42A, Front upper
structure),
-the headlights (see Front headlight: Removal -
Refitting) (80B, Headlights),
-the side air deflectors of the cooling radiator,
-the cooling radiator top air deflector,
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
-the engine undertray,
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
-the engine cover.
a Fill and bleed the cooling system (see 19A, Coo-
ling, Cooling circuit: Draining - Refilling, page
19A-17) .
