10A-85
ENGINE AND CYLINDER BLOCK ASSEMBLY
Multifunction support: Removal - Refitting
K4M
10A
a Disconnect the connector (1) from the air temperatu-
re sensor on the intake manifold.
a Remove the oil filter (see 10A, Engine and cylinder
block assembly, Oil filter: Removal - Refitting,
page 10A-48) .
a Unclip the hoses (2) from the cooling fan assembly.
a Remove:
- the upper bolts (3) from the front end panel,
- the front end panel upper clips (4) .
K4M, and 848
136483
K4M, and 858 or 866
135930
135719
