19D-5
ENGINE MOUNTING
Left-hand suspended engine mounting: Removal - Refitting
K4M
19D
a Unclip the hydraulic clutch pipe from the left-hand
suspended engine mounting cover at (3) .
a Fit the (Mot. 1453) fitted with the (Mot. 1453-01).
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the central bolt (4) from the support of the
left-hand suspended engine mounting rubber pad.
a Gently lower the engine until the rubber pad deta-
ches.
a Remove:
- the bolts (5) for the left-hand suspended engine
mounting rubber pad cover,
K4M, and 858 or 866
136622
135935
135948
K4M, and 848
135931
