19D-27
ENGINE MOUNTING
Right-hand suspended engine mounting: Removal - Refitting
F4R
19D
a Disconnect:
- the petrol vapour rebreathing solenoid valve pipe
(1) ,
- the fuel supply pipe (2) on the injector rail,
a Insert the blanking plugs.
a Unclip the pipes from the cover of the right-hand
suspended engine mounting at (3) .
a Remove:
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) (85A, Wiping -
Washing),
- the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
- the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment).
134645
135779
134644
