19D-26
ENGINE MOUNTING
Right-hand suspended engine mounting: Removal - Refitting
F4R
19D
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the engine cover,
-the engine undertray bolts,
-the engine undertray,
-the lower engine tie-bar (see 19D, Engine moun-
ting, Lower engine tie-bar: Removal - Refitting,
page 19D-33) .
Essential special tooling
Mot. 1453 Multiple-adjusting engine
mounting support with retai-
ning straps.
Mot. 1453-01 Additional winder nut on
engine lift support Mot. 1453.
Essential equipment
safety strap(s)
Tightening tor
quesm
upper engine tie-bar
bolts
115 N.m
bolts for the right-hand
suspended engine
mounting rubber pad
62 N.m
bolts for the right-hand
suspended engine
mounting cover
62 N.m
WARNING
To prevent impurities from entering the circuit, place
protective plugs on all fuel circuit components
exposed to the open air.
