19D-38
ENGINE MOUNTING
Lower engine tie-bar: Removal - Refitting
K4M
19D
a Refit the lower engine tie-bar with its reinforcement.
a Tighten to torque:
-the lower engine tie-bar bolt on the gearbox
(105 N.m),
-the lower engine tie-bar bolt on the front axle
subframe (105 N.m).
a Torque tighten the reinforcement bolt securing
the lower engine tie-bar to the gearbox (105
N.m).
II - FINAL OPERATION
a Refit the engine undertray.
K4M, and 858 or 866
K4M, and 858 or 866
