Research Instruments INTEGRA 3 - Page 58

Secon 10
Integra 3™ Troubleshoong

Research Instruments Ltd
10



 






E06
HEATED INSERT
SENSOR FAILURE
Low /
Medium*
No signal/out of
range signal from
Heated Stage Insert
temperature sensor.
Alarm acvates
at any me if the
temperature sensor
circuit fails to read a
valid temperature.
Temperature
is shown as
-.-°C. Heated
Stage Insert
controller
power is
set to 0%
unl a valid
temperature
is read.
Switch o the
Integra 3 and
verify that the
Heated Stage
Insert cables
and connector
are secure and
undamaged.
Possible heater
or controller
fault.
E07
HEATED STAGE
OVER
TEMPERATURE
Medium
Heated Stage
Plate temperature
has exceeded
the maximum
allowable setpoint
temperature.
Alarm acvates
at any me if the
temperature sensor
exceeds 46°C.
Heated
Stage Plate
controller
power is set
to 0% unl
temperature
falls to
below 46°C.
Temperature
is shown as
-.-°C above
55°C.
Switch o the
Integra 3 and
verify that the
Heated Stage
Plate cables
and connectors
are secure and
undamaged.
Possible heater
or controller
fault.
E08
HEATED STAGE
TEMPERATURE
OUTSIDE ±2.5°C
Medium
Heated Stage Plate
temperature has
deviated more
than 2.5°C away
from the setpoint
temperature. Alarm
enabled 1 minutes
aer reaching
±2.5°C from the
setpoint.
The Heated
Stage Plate
temperature
controller
connues to
operate.
Switch o the
Integra 3 and
verify that the
Heated Stage
Plate cables
and connectors
are secure and
undamaged.
Possible heater
or controller
fault.
* Low priority is set if condion appears within the rst 5 seconds from power up. Medium priority is set if
condion appears aer the rst 5 seconds from power up.
