Secon 10
Integra 3™ Troubleshoong

Research Instruments Ltd
10



 






E13
HEATED
INSERT OVER
TEMPERATURE
Medium
Heated Stage
Insert temperature
has exceeded
the maximum
allowable setpoint
temperature.
Alarm acvates
at any me if the
temperature sensor
exceeds 46°C.
Heated
Stage Insert
controller
power is set
to 0% unl
temperature
falls to
below 46°C.
Temperature
is shown as
-.-°C above
55°C.
Switch o the
Integra 3 and
verify that the
Heated Stage
Insert cables
and connector
are secure and
undamaged.
Possible heater
or controller
fault.
E14
HEATED INSERT
TEMPERATURE
OUTSIDE ±2.5°C
Medium
Heated Stage Insert
temperature has
deviated by more
than 2.5°C away
from the setpoint
temperature.
Alarm enabled
1 minute aer
the temperature
reaches ±2.5°
from the setpoint
temperature.
The Heated
Stage Insert
temperature
controller
connues to
operate.
Switch o the
Integra 3 and
verify that the
Heated Stage
Insert cables
and connector
are secure and
undamaged.
Possible heater
or controller
fault.
