Secon 10
Integra 3™ Troubleshoong

Research Instruments Ltd
10
E22
HEATED
GLASS INSERT
DISABLED
Low /
Medium*
ITO Heated Glass
Insert has come
into electrical
contact with
the with the
microscope
objecve and has
been disabled.
Alarm acvates at
any me.
ITO Heated
Glass Insert
controller
power is set
to 0% for
the duraon
of electrical
contact
with the
microscope
objecve.
The microscope
objecve must
be lowered so
that it does
not touch the
surface of the
ITO Glass.
E23
HEATED INSERT
CONTROLLER
FAILURE
Low /
Medium*
The temperature
controller was not
able to maintain
the temperature of
the Heated Stage
Insert. The Heated
Stage Insert has
been disabled.
Alarm acvates at
any me.
Heated
Stage Insert
controller
power is set
to 0% unl
the
Integra 3 is
re-started.
Switch o the
Integra 3 and
verify that the
Heated Stage
Insert cables
and connector
are secure and
undamaged.
Possible heater
or controller
fault.
E24
FAN SPEED
INCORRECT
Low
Thermosafe Air
Heang System fan
speed is outside
of the normal
operang window.
Alarm enabled
5 minutes aer
power on.
Fan connues
to run in
order to
maintain the
air ow.
Change the
Thermosafe
lter media
pad. Possible
fan or ow
sensor fault.



 






* Low priority is set if condion appears within the rst 5 seconds from power up. Medium priority is set if condion
appears aer the rst 5 seconds from power up.
