C H A P T E R 1
I n t r o d u c t i o n
8 QuadView UHDx/UHDx KVM User Guide 350-12245-01 – updated December, 2019
Control
Web QuadView UHDx Web Controller
Serial Serial 9-pin RS-232 port for command-line control by a PC or third-party control system
Network Network 10/100 Base-T Ethernet for command-line control via Telnet
USB USB 1 × USB 2.0 Type A for firmware update
USB (KVM model only) USB 6 x USB 2.0 Type B for computers/devices being controlled via KVM
USB 1 x USB 2.0 Type A mouse input for KVM control
USB 1 x USB 2.0 Type A keyboard input for KVM control
Power
Power Supply Universal 100-240 VAC, 50-60 Hz
Power Consumption
(maximum)
15 Watts
Environmental
Temperature
Operating (nominal): 32 ºF to 104 ºF (0 ºC to 40 ºC)
Non-Operating: -4 ºF to 140 ºF (-20 ºC to 60 ºC)
Relative Humidity Operating: 20% to 90% non-condensing
Physical
Dimensions See Figure 1-4.
Dimensions are listed in [millimeters] and (inches)
Weight 7.3 lbs. (3.3 kg)
Specifications are subject to change without notice.
Table 1-4 QuadView UHDx and QuadView UHDx KVM Specifications (Continued)
Parameter Description
