350-12245-01 – updated December, 2019 QuadView UHDx/UHDx KVM User Guide 37
C H A P T E R 3
O p e r a t i o n
3.12.4 OSD Control Settings
V I D E O O S D
The Video OSD control enables or disable the on-screen display of video input and network
settings messages:
Enabled: Slide the Video OSD switch to the ON position.
Disabled: Slide the Video OSD switch to the OFF position.
If you disable Video OSD messages and the QuadView UHDx IP address changes as a result of
DHCP being enabled, then use the ASCII command ATM 08 NET_IPA R from a PC or other
controller via the RS-232 interface to retrieve the current IP address. See
“Command Line
Control” on page 41.
A U D I O O S D
The Audio OSD control enables or disable the on-screen display of audio status messages
(volume, mute on, mute off):
Enabled: Slide the Audio OSD switch to the ON position.
Disabled: Slide the Audio OSD switch to the OFF position.
O S D T R A N S PA R E N C Y
You can adjust the OSD message transparency to allow input source images to show through:
1. Enter a value from 0 (opaque) to 5 (highest level of transparency) in the OSD Transparency
field.
2. Click Save.
3.12.5 Input Label Settings
To display the name of each window on the screen:
1. Slide the Source Label switch to the ON position.
2. Select a Font Color by clicking the appropriate radio button. Alternatively, you may choose
Transparent (the leftmost radio button) to display transparent text that allows input source
images to show through.
3. Select a Background Color by clicking the appropriate radio button. Alternatively, you may
choose Transparent (the leftmost radio button) to disable the background.
As you make selections, the Preview area shows you how the labels will appear on the
display output.
4. Click Save when you have finished making changes.
