350-12245-01 – updated December, 2019 QuadView UHDx/UHDx KVM User Guide 51
C H A P T E R 4
C o m m a n d L i n e C o n t r o l
4.3.5 Advanced Commands
Table 4-5 describes the QuadView UHDx advanced commands. These commands provide the
same controls as those found on the Advanced tab of the QuadView UHDx Web Controller. See
“The Advanced Tab” on page 34.
Table 4-5
Advanced Commands
Function Command Feedback Description
Standby/Normal mode ATM 09 POW_CRL W F ~09 POW_CRL W F Switches from Normal to
Standby mode.
ATM 09 POW_WUP W 1 ~09 POW_WUP W 1 Switches from Standby to
Normal mode.
Notes:
This command works only
over a serial connection.
If you send this command
when the QuadView UHDx
is already in Normal mode,
you will receive an
unknown command
message.
Audio Mute ATM 08 AUD_MUT R ~AUD_MUT [0 | F] Reports current audio mute
setting.
ATM 09 AUD_MUT W 0 ~09 AUD_MUT W 0 Mutes the audio output.
ATM 09 AUD_MUT W F ~09 AUD_MUT W F Un-mutes the audio output.
Report Audio Delay
Setting
ATM 08 AUD_DLY R ~AUD_DLY [0...160] Reports current audio delay
setting.
Example: Audio Delay = 120
ms
ATM 08 AUD_DLY R
~AUD_DLY 120
Set Audio Delay ATM 09 AUD_DLY W [0...9] ~09 AUD_DLY W [0...9] Sets audio delay time to [0...9]
ms.
ATM 09 AUD_DLY W
[10...99]
~0A AUD_DLY W [10...99] Sets audio delay time to
[10...99] ms.
ATM 0B AUD_DLY W
[100...160]
~0B AUD_DLY W
[100...160]
Sets audio delay time to
[100...160] ms.
OSD Messages ATM 09 AUD_OSD W
[0 | 1]
~09 AUD_OSD W [0 | 1] Enables/disables audio volume
and mute OSD indications.
0: audio OSD ON
1: audio OSD OFF
ATM 09 VDO_OSD W
[0 | 1]
~09 VDO_OSD W
[0 | 1]
Enables/disables video source
and IP address OSD indications.
0: video OSD ON
1: video OSD OFF
