C H A P T E R 2
I n s t a l l a t i o n
14 QuadView UHDx/UHDx KVM User Guide 350-12245-01 – updated December, 2019
Table 2-1 lists the appropriate KVM connections:
See “(Optional) Using the KVM Function” on page 40 for instructions on using the KVM
function.
To power on the QuadView UHDx:
1. Turn on your display.
2. Turn on your source components.
3. Plug the female end of the supplied power cord into the AC power inlet at the rear of the
QuadView UHDx (AC 100V ~ 240V). See
Figure 1-3.
4. Connect the other end to an AC power source.
5. Turn the main power switch on the rear panel to the ON position.
The switch and front panel PWR indicator both illuminate.
All of the front panel buttons light for approximately three seconds and then go out, except for
the INPUT 1-4, VIDEO 1-4, and STANDBY buttons, which remain on).
Your QuadView UHDx is now ready for use.
Table 2-1 KVM Connections
If the PC or laptop is supplying
video to this port...
...then connect the PC or laptop
to the following USB port.
HDMI 1 1
HDMI 2 2
HDMI 3 3
HDMI 4 4
DISPLAYPORT 5 5
DISPLAYPORT 6 6
2.3 Powering on the QuadView UHDx
I m p o r t a n t
Turn on the display before turning on or resetting the QuadView UHDx to ensure proper
display detection.
