C H A P T E R 3
O p e r a t i on
34 QuadView UHDx/UHDx KVM User Guide 350-12245-01 – updated December, 2019
S TAT I C
To manually configure the QuadView UHDx network interface:
1. Slide the DHCP switch to the OFF position, if it isn’t already.
2. Click Save.
3. Click Network to return to the Network tab.
4. Enter the following values in the appropriate fields:
IP Address: IP address of the QuadView UHDx unit.
Subnet Mask: Divides the IP Address into network and host addresses.
Gateway: This is generally the IP address of the router to which the QuadView UHD xis
connected.
5. Click Save again.
You will need to enter the new IP address into your browser address bar in order to continue using
the QuadView UHDx Web Controller after changing the DHCP or static network settings.
3.11.2 Socket Settings
Most QuadView UHDx applications do not require you to change the default Socket and Port
settings (TCP Server and 23, respectively).
The Advanced tab of the QuadView UHDx Web Controller allows you to manage the following
additional settings:
Power: See “Power Settings” on page 35.
Auto Layout: See “Auto Layout” on page 36.
Audio: See “Audio Settings” on page 36.
OSD Control: See “OSD Control Settings” on page 37.
Input Label: See “Input Label Settings” on page 37.
Serial Port: See “Serial Port Settings” on page 38.
Authentication: See “Authentication Settings” on page 39.
Other: See “Other Settings” on page 39.
N o t e s
Consult your network administrator for assistance with network settings, if needed.
You must include leading zeros when entering values less than 100. For example, enter
192.168.1.200 as
192.168.001.200.
3.12 The Advanced Tab
