This chapter describes all of the features and functions available through the QuadView UHDx
front panel controls, and the QuadView UHDx Web Controller. You may also access these
features and functions via the command-line interface. Refer to
“Command Line Control” on
page 41.
The PWR LED located next to the STANDBY button on the front panel (see Figure 1-1) indicates
the power state of the QuadView UHDx:
Red: Rower is being supplied to the device.
Off: The device is not receiving power. Ensure that the rear panel power switch is in the ON
position, and then check the connection between the power receptacle on the QuadView
UHDx and the AC outlet.
To take the QuadView UHDx out of Standby mode, either:
Press the STANDBY button on the front panel.
Send the ASCII command ATM 09 POW_WUP W 1 from a PC or other controller via the RS-
232 interface.
