C H A P T E R 4
C o m m a n d L i n e C o n t r o l
42 QuadView UHDx/UHDx KVM User Guide 350-12245-01 – updated December, 2019
8. Click OK.
9. Test the connection by typing ATM 08 CSW_VER R.
10. Press [ENTER].
If the connection is working, the QuadView UHDx responds with 08 CSW_VER R followed by the
firmware version and build date. The terminal window is now ready for command control.
To initiate a session with the QuadView UHDx via TCP/IP using a serial link:
1. Connect the QuadView UHDx and automated control system or PC via a serial (RS-232) link.
See Figure 2-3.
2. Launch Tera Term.
3. Select Serial.
4. Select the appropriate COM Port.
5. Click OK.
6. Select Setup > Serial Port....
7. Set the serial port parameters as follows:
Port: Select the port you specified in Step 3.
Baud Rate: 9600.
Data: 8 bit.
Parity: none.
Stop: 1 bit.
Flow Control: none.
Transmit Delay: 0 msec/char and 0 msec/line.
8. Click OK.
9. Follow Steps 6 through 10 of “Connecting to the QuadView UHDx via Telnet/IP” on
page 41.
I m p o r t a n t
Commands are case-sensitive. Alphabetic characters must be in UPPERCASE.
4.2 Connecting to the QuadView UHDx via Serial Link
