RGB Spectrum QuadView UHDx User Manual

RGB
C H A P T E R 3
O p e r a t i on
26 QuadView UHDx/UHDx KVM User Guide 350-12245-01 – updated December, 2019
The Layouts tab of the QuadView UHDx Web Controller allows you to customize, save, and load
a preset or custom screen layout:
 Customize: See “Layout Customization” on page 26 and Figure 3-9.
 Recall: See “Layout Recall” on page 28 and Figure 3-10.
3.9.1 Layout Customization
The Layout Customization area of the Layouts tab appears as shown in Figure 3-9.
Figure 3-9 Layouts > Layout Customization Settings
3.9 The Layouts Tab
N o t e
Layouts only contain window size, position, and priority information. Use the Video Input
controls on the General tab to route sources to windows. See
“Video Settings” on
page 22.
