350-12245-01 – updated December, 2019 QuadView UHDx/UHDx KVM User Guide 43

C H A P T E R 4

C o m m a n d L i n e C o n t r o l

RGB

You may change the QuadView UHDx baud rate using either:

 The Serial Baudrate control on the Advanced tab of the QuadView UHDx Web Controller.

See “The Advanced Tab” on page 34.

 One of the Set Baud Rate commands listed in Table 4-5.

The serial command syntax is as follows:

 Case: Commands are case-sensitive. Alphabetic characters must be in UPPERCASE.

 Spaces: You can use spaces to separate the components of a command for improved

readability. (This option is used in the following command lists.) The QuadView UHDx

command parser ignores spaces; for example, ATM 0A VDO_IPT W 3 2 and

ATM0AVDO_IPTW32 are both valid command strings.

 Command header: ATM

 Length: The total length of the command and parameters, not including the header or spaces,

given in hexadecimal (08 ... 25).

 Command: XXX_XXX

 Read/Write: R/W

 Parameter data: The length and meaning of the parameter data (if required) is dependent on

the command.

4.3.1 General Commands

Table 4-1describes the general QuadView UHDx general commands. These commands provide

the same controls as those found on the General tab of the QuadView UHDx Web Controller

interface. See

“The General Tab” on page 22.

4.3 Command Syntax and Lists

N o t e

You need not send a carriage return or press [ENTER] following the command when using a

serial connection.

Table 4-1 General Commands

Function Command Feedback Description

Report Input Name ATM 09 IPT_NAM R [1…6] ~INPUT[1...6]:

[input_name]

Reports the name of Input

[1...6].

Example:

Input 1 name = CAMERA

ATM 09 IPT_NAM R 1

~INPUT1: CAMERA
