C H A P T E R 4
C o m m a n d L i n e C o n t r o l
44 QuadView UHDx/UHDx KVM User Guide 350-12245-01 – updated December, 2019
Set Input Name ATM [0A...15] IPT_NAM W
[1…6] [input_name]
~[0A...15] IPT_NAM W
[1…6][input_name]
Sets the name of Input [1...6].
The name can be up to 12
characters long and can include
letters, numbers, spaces, and
some special characters.
The length of the input name
affects the length of the
command, which you must
specify (in hex) following the
ATM header. For example, a
one-character name results in a
command length of 0A; a 12-
character name results in a
command length of 15.
Examples:
Input 3 name = pc
ATM 0B IPT_NAM W 3 pc
Input 1 name = CAMERA
ATM 0F IPT_NAM W 1
CAMERA
Input 2 name = ZioDecoder01
ATM 15 IPT_NAM W 2
ZioDecoder01
Report Window/Input
Pairs
ATM 08 VDO_IPT R ~VDO_IPT A1 [1...6]
B1 [1...6] A2 [1...6]
B2 [1...6]
Reports inputs assigned to each
window.
Example:
Window 1 (A1) -> Input 5
Window 2 (B1) -> Input 6
Window 3 (A2) -> Input 3
Window 4 (B2) -> Input 4
ATM 08 VDO_IPT R
08 VDO_IPT R
~VDO_IPT A1 5 B1 6 A2 3
B2 4
Source-to-Window
Routing
ATM 0A VDO_IPT W [1…4]
[1…6]
~0A VDO_IPT W [1…4]
[1…6]
Routes Input [1…6] to Window
[1…4].
Example: To route Input 2 to
Window 3, use the command:
ATM 0A VDO_IPT W 3 2
Report Aspect Ratio ATM 08 WIN_RAT R ~WIN_RAT A1 [1...4] B1
[1...4] A2 [1...4]
B2 [1...4]
Reports aspect ratio for
Windows A1 (1), B1 (2), A2 (3),
and B2 (4), as follows:
1: Normal
2: FULL
3: 16:9
4: 4:3
Table 4-1 General Commands (Continued)
Function Command Feedback Description
