350-12245-01 – updated December, 2019 QuadView UHDx/UHDx KVM User Guide 47
C H A P T E R 4
C o m m a n d L i n e C o n t r o l
Input Cropping
(continued)
ATM 0A CRO_PIN R E
[1...6]
~CRO_PIN R E[0 |
1],S[1...6],Xxxxx,Yyyyy,Ww
www,Hhhhh
Reports enabled/disabled
status, position (X/Y) and size
(W/H) of visible region for Input
[1...6].
Example: Cropping enabled on
Input 4; source rectangle is 800
× 600 with origin at 100, 100
ATM 0A CRO_PIN R E 4
~CRO_PIN R
E1,S4,X0100,Y0100,
W0800,H0600
ATM 25 CRO_PIN W
E[0 | 1],S[1...6],Xxxxx,
Yyyyy,Wwwww,Hhhhh
~25 CRO_PIN W [1...6]
Xxxxx,Yyyyy,Wwwww,
Hhhhh
Sets enabled/disabled status,
position (X/Y) and size (W/H) of
visible region for Input [1...6].
Example: Enable cropping on
Input 4; set source rectangle to
800 × 600 with origin at 100, 100
ATM 25 CRO_PIN W
E1,S4,X0100,Y0100,
W0800,H0600
~25 CRO_PIN W 4
X0100,Y0100,
W0800,H0600
Report Current Audio
Input
ATM 08 ADO_IPT R ~ADO_IPT [1...6] Reports currently-selected audio
input.
Example: Input 6
ATM 08 ADO_IPT R
~ADO_IPT 06
Select Audio Input ATM 09 ADO_IPT W [1…6] ~09 ADO_IPT W [1…6] Routes Audio Input [1…6] to
audio outputs.
Example:
To route audio Input 4 to the
audio outputs, use the
command:
ATM 09 ADO_IPT W 4
Report Audio Volume
Setting
ATM 08 VOL_CRL R ~VOL_CRL [0...10] Reports current volume setting.
Example: Volume = 10
ATM 08 VOL_CRL R
~VOL_CRL 10
Set Audio Volume ATM 09 VOL_CRL W 0 ~09 VOL_CRL W 0 Mutes audio output.
ATM 09 VOL_CRL W [1…9] ~09 VOL_CRL W [1…9] Sets program audio output
volume to [1…9].
ATM 09 VOL_CRL W A ~09 VOL_CRL W A Sets program audio output
volume to 10.
ATM 09 VOL_CRL W E ~09 VOL_CRL W E Increases program audio output
by one increment.
Table 4-1 General Commands (Continued)
Function Command Feedback Description
To Next Page
