Ricoh Aficio SP 5200S - Page 176

2. Push the button on the right side of the machine to open the front cover.
CFF004
1
2
3. Hold the print cartridge's front handle to lift and pull it out.
CFF008
1
2
4. Wipe around the metallic registration roller by turning with a soft damp cloth. After that,
wipe it with a dry cloth to remove the moisture.
CEC040
9. Remarks
174
