Ricoh Aficio SP 5200S - Page 75

11. Lower the ADF.
CFE081
12. Push the button on the right side of the machine to open the front cover.
CFE078
1
2
13. Hold the print cartridge's front handle to lift and pull it out.
CFE068
1
2
Place the print cartridge on a stable, flat surface.
14. Remove the protective material attached on the machine's interior.
Installing the Machine
73
