Ricoh D5510 - Logging in

8. Open [Configure TCP/IP Port Monitor].
If [Configure TCP/IP Port Monitor] is not displayed on the window, proceed to the next step.
9. Under [Protocol], select "LPR".
10. Under [LPR Settings], in Queue Name, specify the name of the printer installed on
the server.
11. Under [LPR Settings], select the [LPR Byte Counting Enabled] checkbox.
12. Close [Printer Properties].
13. Click [Set] on the Print Settings window.
Specify a background for the login screen
You can specify an image to be used as the background for the login screen from User
Authentication Settings on the Administrator Settings Web page.
• Before reconfiguring Print Settings as described above, check that a supported printer or
multifunction printer is correctly connected to the machine.
• The image file to be used as the background for the login screen should be a JPEG file of less than
20 MB.
• If RICOH Streamline NX-based authentication is enabled, the e-mail address of the logged-in user
being logged in will be automatically set as the destination and sender addresses.
Logging in
If the authentication function of the machine is enabled, the login screen is displayed when the machine
starts up or returns from the standby mode.
Once you have successfully logged in, all whiteboard functions will be available.
When using your IC card
10. Appendix
246
