Item Specifications
Communication connector
Controller Unit
10BASE-T/100BASE-TX/1000BASE-T
• For the external interfaces other than Capture Board and Controller Unit, see "Read This First".
Network
Item Specifications
Line speed Minimum: 200 kbps
Communication port Remote whiteboard
• TCP: 80, 50000, 50001, 50002, and 61616 are available
for communication
E-mail transmission
• Communication with the port number specified in the Email
settings is available for communication. (page 157
"Configuring SMTP Server Settings")
RICOH UCS function
• When no proxy is used
TCP: 80, 443, 5222, 17990, 17992
UDP: 50000 – 65535 (Maximum 6 ports)
• When a proxy is used
TCP: 80, 443
• TCP443 transmission
TCP: 80, 443
Folder sharing on external storages
• TCP 445, UDP 53, and TCP/UDP 137 are available for
communication
Power source
Item Specifications
Power source used 100–240 V, 50 Hz/60 Hz
Maximum power consumption Less than 300 W
10. Appendix
278
