External Interface (Controller)
Item Specifications
Input connector
Capture Board
Digital Input (Correspond to HDMI)×1
• Digital Input (Copyright-protected content not
supported)
DisplayPort terminal×1
• DisplayPort Input (Copyright-protected content not
supported)
Mini D-SUB15Pin×2
• VGA Input
Controller Unit
Microphone Input×1
• Audio Input
• For details about the video input signals that are supported,
see page 266 "List of Video Input Signals Supported by the
Machine".
Output connector
Controller Unit
Digital Output (Correspond to HDMI)×1
• Digital Output (For audio-visual devices)
Speaker terminal
• Audio Output
(Line Out/Stereo)
USB Port
Controller Unit
USB2.0 TypeA (1):
For connecting USB device such as a USB flash memory
device.
USB2.0 TypeA (2):
For connecting the Pen Sensor Kit. This terminal can also be
used for connecting a device such as a USB flash memory
device when the Pen Sensor Kit is not connected.
USB3.0 TypeA:
For connecting the Capture Board only. This terminal cannot
be used for other purposes.
Specifications
281
