2.11.21 Standard resistance values of the ADF/SADF original size sensors
SADF (KΩ) ADF KΩ Size
10.12 8.75 MAX
9.20 8.24 A3
6.20 5.46 B4
2.48 2.14 A4
0.17 0.23 B5
0 0.05 MIN
2.11.22 LED’s on the ADF control board
LED No. Sensor Name
100 1st reverse sensor
101 Original set sensor
102 2nd transport sensor
103 Entrance sensor
104 ADF exit sensor
105 1st transport sensor
106 SADF exit sensor
107 Registration sensor
108 2nd reverse sensor
109 Recycle arm sensor
110 SADF set sensor
111 Stays ON
112 Stays ON
113 Stays ON
114 Recycle arm height sensor
1 July 1994
ADF
2-107
