Ricoh FT9101 - Page 197

4. TABLE OF PM ITEMS
C: Cleaning R: Replacement L: Lubrication, greasing A: Check and adjust
Cycle
Item
Every visit As
necessary
200K 400K 600K 800K 1M 1.2M 1.4M 1.6M 1.8M 2M 2.2M 2.4M 2.6M 2.8M 3M Remarks
Optics
Exposure glass
C R C C C C C C C C C C C C C C C
Clean with glass
cleaner, then wipe
with silicon oil.
Check the resistance.
1st mirror
C C C C C C C C C C C C C C C
Silicon cloth
2nd mirror
C
Silicon cloth
Reflectors
C C C C C C C C C C C C C C C
Silicon cloth
Xenon lamp
R R R
Lens motor drive
gear
L L
Mobil Temp. 78
Lens motor timing
belt
A A
Rear cooling, flash
blower, exposure
cooling, and flash
power cooling fan
filters inside the
left cover and flash
power inside
blower filter on the
rear left cover
C C C C C C C C C C C C C C C
Remove dust
Lens
C C C C C C C C C C C C C C C
Blower brush
OPC
OPC belt
R R R R R R R R R R R R R R R
OPC cleaner pad
C C C C C C C C
Alcohol
OPC drive roller
C C C C C C C
Wipe with dry cloth
(ether and toluene not
allowed)
OPC sensor
C C C C C C C
Blower brush
Quenching lamp
cover
C C C C C C C
Wipe with dry cloth
OPC motor timing
belt
R A A A
Front and rear
ground brushes
C C C C C C C
Wipe with dry cloth
Front and rear
sliders
L L L
G-40M
4-1
