Shift tray rise mode
DIP101 DIP102
1 2 3 4 1 2 3 4
1 0 0 0 0 0 0 0
In this mode, the shift tray moves to its uppermost
position if the copy paper stacked on the tray is removed
while copying.
NTOE:
When the stapling copy mode is used with the shift
tray rise mode, the shift tray moves up and down
slightly for each stapled copy set delivered to the
tray.
3.8.4 Inverter control PCB DIP switch table
Factory setting
DIP100 DIP101
1 2 3 4 1 2 3 4
0 0 0 0 0 0 0 0
0: OFF
Free run test mode
DIP100 DIP101
1 2 3 4 1 2 3 4
0 0 0 0 0 1 0 0
0: OFF 1: ON
Free run test mode starts when the finisher and inverter
front doors are closed, and stops when one of them is
opened.
Finisher Electrical Components 1 July 1994
3-12
