Ricoh FT9101 - Page 201

C: Cleaning R: Replacement L: Lubrication, greasing A: Check and adjust
Cycle
Item
Every visit As
necessary
200K 400K 600K 800K 1M 1.2M 1.4M 1.6M 1.8M 2M 2.2M 2.4M 2.6M 2.8M 3M Remarks
Fusing
Fusing roller
C C R C R C R C R C R C R C R C
Wipe with dry cloth
Heat insulating
bushings
R R R R R R R
Barrierta
Fusing roller
bearings
R R R
Fusing roller
spacers
R R R
Pressure roller
C C C C R C C C R C C C R C C C
Pressure roller
bearings
R R R
Fusing pick-off
pawls
C R C C C C C C C C C C C C C C C
Wipe with toluene
Metering blade
R R R R R R R R R R R R R R R
Cleaning blade
R R R R R R R R R R R R R R R
Side blades
C C C C C C C
Alcohol
Oil supply pad
R R R R R R R R R R R R R R R
Fusing thermistor
C C C C C C C
Wipe with alcohol
Oil pump tube
R R R
Fusing drive joint
gear
L L L L L L L
Mobil Temp. 78
Fusing entrance
guide plates
C C C C C C C C C C C C C C C
Wipe with toluene
Each transport
roller
C C C C C C C
Alcohol
Drive gears
L L L L L L L
Mobil Temp. 78
Silicon oil
A A A A A A A A A A A A A A A
Oil pan
C C C C C C C
Wipe with dry cloth
Oil path
C C C C C C C C C C C C C C C C
Wipe with dry cloth
Oil tube and oil
tank
R
4-5
