Ricoh FT9101 - Page 202

C: Cleaning R: Replacement L: Lubrication, greasing A: Check and adjust
Cycle
Item
Every visit As
necessary
200K 400K 600K 800K 1M 1.2M 1.4M 1.6M 1.8M 2M 2.2M 2.4M 2.6M 2.8M 3M Remarks
Main Body
Ozone filter
R R R
Main timing belt
A A
Filters for front
cooling and
cleaning unit
cooling fans, etc.
C C C C C
Process control
setting A
A A A
ADF
Transport belt
C C C R C C R C C R C C R C C R
Belt cleaner
Original set sensor
C C C C C C C C C C C C C C C
Blower brush
ADF exit sensor
C C C C C C C C C C C C C C C
Blower brush
Recycle arm
sensor
C C C C C C C C C C C C C C C
Blower brush
Vacuum belts
R C C C C C C C C C C C C C C C
Alcohol
All transport rollers
C C C C C C C C C C C C C C C
Alcohol
Black mats for
sensor
C C C C C C C C C C C C C C C
Blower brush
Shutter solenoid
A
LCT
Pick-up roller
R R R R R R R
Paper feed roller
R R R R R R R
Reverse roller
R R R R R R R
Tray drive gear
L L L
Mobil Temp. 78
Paper end sensor
C C C
Blower brush
Transport sensor
C C C C C
Blower brush
All transport rollers
C C C
Water
4-6
