5.1.5 AID reference voltage screen [4-03]
When the Start key is pressed, the light reflected from the original
on the exposure glass exposes the OPC surface. The OPC
potential is measured and indicated in this window. This is
repeated 10 times and is stopped automatically.
NOTE:
In normal copying, the AID reference voltage is used to determine
the development bias level in the auto image density mode to
meet the original background density.
Shows the number of steps for
compensated development bias
determined by the above AID
reference voltage.
1 July 1994 Service Tools Display
5-3
