Ricoh FT9101 - Page 288

Fan motors
Duplex blower
Flash power cooling fan
Flash power inside blower
Front curl remove fan
Fusing cooling exhaust fan
Rear curl remover fan
Vacuum fan
Inside and outside ozone exhaust fans
ID sensor blower
Cleaning coil cooling fan
PCB cooling fan
DC power cooling fan
Exposure cooling fan
Flash blower
Rear cooling fan
2nd fusing cooling blower
1st fusing cooing blower
Front cooling fan
Inner cover cooling fan
Eraser blower
Cleaning inside cooling fan
1 July 1994 Electrical Component Layout Diagram
1-21
