Motors and solenoids
Duplex feed motor
Duplex vacuum solenoid
Air knife solenoid
Development motor
Registration motor
Eject junction solenoid
Jogger motor
Back fence motor
Paper feed motor
Tray motor
Humidity sensor
Main motor
Agitator motor
Toner supply motor
Pick-up solenoid
OPC cleaning motor
OPC cleaning brush drive solenoid
Tracking motor
OPC motor
Oscillating motor
OPC cleaning brush pressure solenoid
Left shield motor
Right shield motor
Charge wire cleaner motor
Power supply terminal block
Noise filter
Circuit breaker
Relay 1
Relay 2
Duplex entrance junction solenoid
Mirror/lens motor
Electrical Component Layout Diagram 1 July 1994
1-20
