2.5 Erase
2.5.1 Main construction
Structural diagram
Construction
186 LEDs erase unwanted areas from the electric latent
image formed on the OPC.
Contamination of eraser by toner is prevented by air flow.
Eraser
OPC
Eraser
Erase Erase mechanism
Eraser blower mechanism
Erase
1 July 1994
2-44
