1.9.2 Removing the clamps
CAUTION
Unplug the copier power cord before starting
the following procedure.
1. Remove the strips of filament tape on the finisher
and remove the styrofoam blocks.
2. Remove the fixing screw and cut the bind for the
stapler using pliers.
Styrofoam
blocks
Filament
tape
Filament
tape
Filament
tape
Filament
tape
Filament
tape
Bind
Fixing screw
1 July 1994
Finisher Installation
1-37
