See Page 82
37. ADF DRIVE SECTION (A112)
See Page 86
39. ADF TRANSPORT SECTION (A112)
See Page 84
38. ADF INVERTER SECTION (A112)
See Page 88
40. ADF INTERMEDIATE TRANSPORT UNIT
(A112)
FT9101 9 Parts Location and List
