PRINTER ENGINE SERVICE MODE
SM 5-11 G065
Service
Tables
SP2 Mode Number Function and [Setting]
06 Back Side – Right Adjusts the right side erase margin in the
reverse side of duplex prints.
[0 ~ 9.0 / 0.3 / 0.1 mm step]
Recommend: 2
±
1.5 mm
2101*
07 Back Side – Left Adjusts the left side erase margin in the reverse
side of duplex prints.
[0 ~ 9.0 / 0.3 / 0.1 mm step]
Recommended: 2 +2.5/–1.5 mm
LD Power Adjust Adjusts the intensity of the laser for the printer.
The printer and fax settings can be adjusted
separately.DFU
01 LD1 Print Control
02 LD2 Print Control
(–55 ~ +64 / –20 /1 LSB step)
Approx. 50/128 = 0.4%
03 LD1 Printer
04 LD2 Printer
(–55 ~ +64 / –5 /1 LSB step)
Approx. 50/128 = 0.4%
05 LD1 Adjustment Start/End DFU
2103*
06 LD2 Adjustment Start/End DFU
LD Beam Pitch Adjustment
Adjusts the beam gap for the dual beam system. After replacing the LD unit or
replacing or clearing the NVRAM, use this SP mode to adjust the laser beam pitch.
This adjustment is performed by specifying the number of pulses to the stepper
motor that will adjust the angle of rotation of the LD unit from the home position.
01 400 dpi Adjusts the laser beam pitch value for 400 dpi
resolution.
400 dpi: [8 ~ 262 / 144 / 1 pulse step]
After replacing the LD unit or replacing or
clearing NVRAM, use this SP and SP2109-03 to
adjust the laser beam pitch.
02 600 dpi
Adjusts the laser beam pitch value for 600 dpi
resolution.
600 dpi: [28 ~ 284 / 168 / 1 pulse step]
After replacing the LD unit or replacing or
clearing NVRAM, use this SP and SP2109-04 to
adjust the laser beam pitch.
03 400 dpi Initial Setting Initializes the laser beam pitch for 400 dpi using
the value for SP2109-01.
After entering a value for SP2109-1, this SP
must be executed.
04 600 dpi Initial Setting Initializes the laser beam pitch for 600 dpi using
the value for SP2109-02.
After entering a value for SP2109-02, this SP
must be executed.
2109*
05 Auto Interval Set Sets the interval for automatic laser beam pitch
adjustment.
[0 ~ 65,535 / 10,000 / 1 step]
When the number of times that the resolution
has been changed reaches this value, the laser
unit position is automatically corrected.
