Ricoh IM C2000 Series User Manual

Specify the port to use for the connection between the computer and machine using one of the
following methods:
To specify the IP address
1. Enter the IP address of the machine, and then click [Next].
2. Proceed to Step 9.
To select from the port list
1. Select the port to use for the connection between the computer and machine, and then
click [Next].
2. Proceed to Step 9.
To create a new port
1. Select [Specify a new port], and then click [Next].
2. On the "Add Printer and Utility Wizard" screen, select [Standard TCP/IP Port] and click
[Next].
3. On the "Add Standard TCP/IP Printer Port Wizard" screen, click [Next].
4. On the "Add port" screen, enter the printer name or IP address of the machine, and then
click [Next].
The port name is automatically entered. You can change the port name.
5. When the "Additional port information required" screen is displayed, select [RICOH
Network Printer C model], and then click [Next].
6. Click [Finish].
9. Specify the name of the printer to install, and whether to use it as the default printer.
Installing the Printer Driver for Network Connection (Windows)
111

Ricoh IM C2000 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	2, 300 sheets
Duplex Printing	Yes
Standard Memory	2 GB
Power Consumption (Maximum)	1.3 kW
Copy Speed (Color)	20 cpm
Copy Speed (Mono)	20 cpm
Copy Resolution	600 x 600 dpi
Print Speed	20 ppm
Scan Resolution	600 dpi
Connectivity	USB, Ethernet, Wi-Fi
First Print Time (Color)	7.5 seconds or less
Supported Paper Sizes	A3, A4, A5, B4, B5
Paper Weight	52 - 300 gsm
Hard Disk Drive	320 GB
Power Source	50/60Hz
Fax Resolution	200 x 200 dpi
